The EC-PG503-05 extension card supports the input of absolute position signals and integrates the
advantages of absolute and incremental encoders. It is user-friendly, adopting spring terminals.

EC-PG503-05 terminal function description

Label
PWR
PGND
A1+
A1-
B1+
B1-
Z1+
Z1-
A2+
A2-
B2+
B2-
Z2+
Z2-
AO+
AO-
BO+
Definition
State indicator
Disconnection indicator
Power indicator
Name
Encoder power
Encoder interface
Pulse setting
Frequency-divided
output
This indicator is on when the extension card is
establishing a connection with the control board; it
blinks periodically after the extension card is
properly connected to the control board (the
period is 1s, on for 0.5s, and off for the other
0.5s); and it is off when the extension card is
disconnected from the control board.
This indicator is off when A1 and B1 of the
encoder is disconnected; and it is on when the
pulses are normal.
This indicator is on after the control board feeds
power to the PG card.
Function description
Voltage: 5 V±5%
Max. current: 200 mA
1. Differential incremental PG interface of 5 V
2. Response frequency: 400 kHz
1. Differential input of 5 V
2. Response frequency: 200 kHz
1. Differential output of 5 V
2. Supporting frequency division of 1–255, which
can be set through P20.16 or P24.16
