Goodrive350 series high-performance multi-function inverter
Function
Closed-loop setting
Closed-loop feedback
Input state
Output state
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read input of
high-speed pulse 1
Read input of
high-speed pulse 2
Read current step of
multi-step speed
External length
External count value
Torque setting
Identification code
Fault code
The Read/Write (R/W) characteristics indicate whether a function can be read and written. For
example, "Communication-based control command" can be written, and therefore the command code
6H is used to control the inverter. The R characteristic indicates that a function can only be read, and
W indicates that a function can only be written.
Note: Some parameters in the preceding table are valid only after they are enabled. Take the running
and stop operations as examples, you need to set "Running command channel" (P00.01) to
"Communication", and set "Communication running command channel" (P00.02) to the Modbus
communication channel. For another example, when modifying "PID setting", you need to set "PID
reference source" (P09.00) to Modbus communication.
The following table describes the encoding rules of device codes (corresponding to the identification
code 2103H of the inverter).
8 MSBs
01
Address
3008H -100.0–+100.0% (unit: 0.1%)
3009H -100.0–+100.0% (unit: 0.1%)
300AH 000–1FF
300BH 000–1FF
300CH 0.00–10.00V (unit: 0.01V)
300DH 0.00–10.00V (unit: 0.01V)
300EH -10.00–10.00V (unit: 0.01V)
300FH
3010H 0.00–50.00kHz (unit: 0.01Hz)
3011H
3012H 0–15
3013H 0–65535
3014H 0–65535
3015H -300.0–+300.0% (unit: 0.1%)
3016H
5000H
Meaning 8 LSBs
GD
Data description
0x08
0x09
0x0a
0xa0
-258-
Meaning
GD35 vector inverter
GD35-H1 vector inverter
GD300 vector inverter
GD350 vector inverter
Chapter 9
R/W
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
