INVT Goodrive350 Series Operation Manual page 269

Goodrive350 series high-performance multi-function inverter
Function
Communication-based
control command
Communication-based
value setting
In the actual operation, set P00.01 to 2 and P00.06 to 8.
The command transmitted by the master is as follows:
01 10
Continuous
Inverter
address write
command
If the operation is successful, the following response is returned:
Inverter
address
Example 2: Set "Acceleration time" of the inverter whose address is 01H to 10s, and "Deceleration
time" to 20s.
Function
code
Acceleration
P00.11
Deceleration
P00.12
The address of P00.11 is 000B, 10s is 0064H in the hexadecimal form, and 20s is 00C8H in the
Address
2000H
2001H
2002H
20 00 00 02
Parameter
Parameter
address quantity
01 10
Continuous
write
command
Name
Acceleration time is the time needed for accelerating
from 0Hz to max. output frequency (P00.03).
Deceleration time is the time needed from
time 1
decelerating from max. output frequency (P00.03) to
0Hz.
Goodrive350 series inverter defines four groups of
acceleration and deceleration time, which can be
selected via multi-function digital input terminal (P05
group). The acceleration/deceleration time of the
time 1
inverter is the first group by default.
Setting range of P00.11 and P00.12: 0.0–3600.0s
Data description
0001H: Forward running
0002H: Reverse running
0003H: Forward jogging
0004H: Reverse jogging
0005H: Stop
0006H: Coast to stop (emergency stop)
0007H: Fault reset
0008H: Jogging to stop
Communication-based frequency setting (0 –
Fmax, unit: 0.01 Hz)
PID setting, range
corresponding to 100.0%)
04
Number of
bytes
20 00 00 02
Parameter
Parameter
address quantity
Detailed parameter description
-264-
(0 –
1000, 1000
00 01 03 E8
Froward
10 Hz
running
4A 08
CRC
Default
v alue
Depend
on model
Depend
on model
Chapter 9
R/W
R/W
R/W
3B 10
CRC
Modi
fy
○
○
