Goodrive350 series high-performance multi-function inverter
Function
Name
code
Torque set by
P03.12
keypad
Torque reference
P03.13
filter time
Source of upper
limit frequency
P03.14 setup of forward
rotation in torque
control
Source of upper
limit frequency
P03.15 setup of reverse
rotation in torque
control
Keypad limit
P03.16
value of upper
Detailed parameter description
above)
11: Set via EtherCat/Profinet communication
12: Set via PLC
-300.0%–300.0% (rated motor current)
0.000–10.000s
0: Keypad (P03.16)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: MODBUS communication (the same as above)
7: PROFIBUS /CANopen/ DeviceNet communication
(the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
0: Keypad (P03.17)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: MODBUS communication (the same as above)
7: PROFIBUS /CANopen/ DeviceNet communication
(the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: Source 1-11, 100% relative to the max.
frequency
This function code is used to set frequency limit.
100% corresponds to the max. frequency. P03.16
-135-
Chapter 6
Default Modi
value fy
20.0%
○
0.010s
○
0
○
0
○
50.00Hz
○
