INVT Goodrive350 Series Operation Manual page 70

Goodrive350 series high-performance multi-function inverter
Function
code
Source of upper
limit frequency
P03.15 setup of reverse
rotation in torque
Keypad limit value
of upper limit
P03.16 frequency of
forward rotation in
torque control
Keypad limit value
of upper limit
P03.17 frequency of
reverse rotation in
torque control
P03.18 Source of upper
Name
6: MODBUS communication (the same as
above)
7: PROFIBUS /CANopen/ DeviceNet
communication (the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: Source 1-11, 100% relative to the max.
frequency
0: Keypad (P03.17)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: MODBUS communication (the same as
above)
7: PROFIBUS /CANopen/ DeviceNet
communication (the same as above)
control 8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: Source 1-11, 100% relative to the max.
frequency
0.00Hz–P00.03 (max. output frequency)
0.00Hz–P00.03 (max. output frequency)
0: Keypad (P03.20)
Detailed parameter description
-65-
Chapter 5
Default
value
0
50.00 Hz
50.00 Hz
0
