Goodrive350 series high-performance multi-function inverter
4.2.4 Single-unit installation
A
B
A
Note: The min. dimension of B and C is 100mm.
4.2.5 Multiple-unit installation
A
B
A
Note:
1.
When users install inverters in different sizes, align the top of each inverter before installation for
the convenience of future maintenance.
2.
The min. dimension of B, D and C is 100mm.
B
Fig 4.3 Single-unit installation
D
B
Fig 4.4 Parallel installation
-19-
Chapter 4
C
Hot air
Cold air
C
Hot air
C
Cold air
C
