Goodrive350 series high-performance multi-function inverter

Appendix A Extension cards

A.1 Model definition
Field identifier
①
②
③
④
⑤
EC - PG 5 01 – 05
①
Field description
Product category
Card category
Technical version
Distinguishing code
Working power
② ③ ④
Naming example
EC: Extension card
PG: PG card
PC: PLC programmable card
IO: IO extension card
TX: Communication extension card
Indicates the generation of a technical version by
using odd numbers, for example, 1, 3, and 5
st nd
indicate the 1 , 2
technical version.
01: Incremental PG card + frequency-divide output
02: Sine/Cosine PG card + pulse direction setting +
frequency-divide output
03: UVW PG interface + pulse direction setting +
frequency-divide output
04: Resolver PG interface + pulse direction setting +
frequency-divide output
05: Incremental PG card + pulse direction setting +
frequency-divide output
06: Absolute PG interface + pulse direction setting +
frequency-divide output
07: Reserved 2
00: Passive
05: 5V
12: 12–15 V
24: 24 V
-268-
⑤
rd
, and 3 generations of the
