INVT Goodrive350 Series Operation Manual page 147

Goodrive350 series high-performance multi-function inverter
Function
Name
code
V/F voltage point
P04.17
1 of motor 2
V/F frequency
P04.18
point 2 of motor 2
V/F voltage point
P04.19
2 of motor 2
V/F frequency
P04.20
point 3 of motor 2
V/F voltage point
P04.21
3 of motor 2
V/F slip
P04.22 compensation
gain of motor 2
Low-frequency
P04.23 oscillation control
factor of motor 2
High-frequency
P04.24 oscillation control
factor of motor 2
Oscillation
P04.25 control threshold
of motor 2
Energy-saving
P04.26
run
Channel of
P04.27
voltage setup
Detailed parameter description
0.0%–110.0% (rated voltage of motor 2)
P04.16– P04.20
0.0%–110.0% (rated voltage of motor 2)
P04.18– P12.02 (rated frequency of asynchronous
motor 2)
Or P04.18– P12.16 (rated frequency of synchronous
motor 2)
0.0%–110.0% (rated motor voltage)
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (max. output frequency)
0: No action
1: Automatic energy-saving operation
Under light-load state, the motor can adjust the
output voltage automatically to achieve
energy-saving purpose
0: Keypad; output voltage is determined by P04.28
1: AI1
2: AI2
3: AI3
4: HDIA
5: Multi-step (the set value is determined by P10
group)
6: PID
7: MODBUS communication
-142-
Chapter 6
Default Modi
value fy
00.0%
○
0.00Hz
○
00.0%
○
0.00Hz
○
00.0%
○
0.0%
○
10
○
10
○
30.00Hz
○
0
◎
0
○
