cancelled by setting P07.00 to 0; if P01.00 is set to a non-zero value, the parameter will be protected
by password. When modifying function parameters through serial communication, the function of user
password also follows above rules.
Function
Name
code
P00 group Basic functions
Speed control
P00.00
mode
Running
P00.01 command
channel
Communication
running
P00.02
command
channel
Max. output
P00.03
frequency
Upper limit of
P00.04 running
frequency
Lower limit of
P00.05 running
frequency
Detailed parameter description
0:SVC 0
1:SVC 1
2:SVPWM
3:VC
Note: If 0, 1 or 3 is selected, it is required to carry out
motor parameter autotuning first.
0: Keypad
1: Terminal
2: Communication
0:MODBUS
1:PROFIBUS/CANopen/Devicenet
2:Ethernet
3:EtherCat/Profinet
4:PLC programmable card
5:Bluetooth card
Note: 1, 2, 3, 4 and 5 are extended functions which
are applicable with corresponding cards.
Used to set the max. output frequency of the inverter.
It is the basis of frequency setup and the
acceleration/deceleration.
Setting range: Max (P00.04, 10.00) –630.00Hz
The upper limit of running frequency is upper limit
value of inverter output frequency. This value should
be no more than the max. output frequency.
When the set frequency is higher than the upper limit
frequency, the inverter runs at the upper limit
frequency.
Setting range: P00.05–P00.03 (max. output
frequency)
The lower limit of running frequency is the lower limit
value of inverter output frequency.
When the set frequency is lower than the lower limit
frequency, the inverter runs at the lower limit
frequency.
