INVT Goodrive350 Series Operation Manual page 199

Goodrive350 series high-performance multi-function inverter
Function
Name
code
Count value of
P18.20
resolver
P18.21 Resolver angle
Pole angle of
closed-loop
P18.22
synchronous
motor
State control
P18.23
word 3
High bit of count
P18.24 value of pulse
reference
Low bit of count
P18.25 value of pulse
reference
Spindle reduction
P18.26
ratio
Encoder UVW
P18.27
sector
Encoder PPR
(pulse-per-
P18.28
revolution)
display
Angle
compensation
P18.29 value of
synchronous
motor
Reserved
P18.30
variables
Pulse reference
P18.31
Z pulse value
P18.32– Reserved
P18.35 variables
P19 group Extension card state check
Detailed parameter description
Count value of resolver.
Range: 0–65535
The pole position angle read according to the
resolver-type encoder.
Range: 0.00–359.99
Current pole position.
Range: 0.00–359.99
0–65535
0–65535
0–65535
It is the drive ratio (speed ratio) between the
mounting shaft and the spindle of the encoder when
spindle stops accurately.
Range: 0.000–65.535
0–7
0–65535
-180.0–180.0
0–65535
0–65535
0–65535
-194-
Chapter 6
Default Modi
value fy
0
●
0.00
●
0.00
●
0
●
0
●
0
●
0.000
●
0
●
0
●
0.00
●
0
●
0
●
0
●
