Functio
n code
P01.03 DC brake current before start 0.0–100.0%
P01.04 DC brake time before start
Acceleration/deceleration
P01.05
P01.08
Starting frequency of DC
P01.09
Waiting time of DC brake after
P01.10
P01.11 DC brake current of stop
P01.12 DC brake time of stop
Deadzone time of
P01.13
forward/reverse rotation
Forward/reverse rotation
P01.14
switch-over mode
P01.15
P01.16 Stop speed detection mode
Power-on terminal running
P01.18
protection selection
Action selection when the
running frequency is below
P01.19
lower limit (lower limit should
be larger than 0)
P01.20 Wake-up-from-sleep delay
P01.21 Restart after power cut
P01.22 Waiting time of restart after
Name
mode
Stop mode
brake after stop
stop
Stop speed
Detailed parameter description
0.00–50.00s
0: Straight line
1: S curve
Note: If mode 1 is selected, it is required
to set P01.07, P01.27 and P01.08
accordingly
0: Decelerate to stop
1: Coast to stop
0.00Hz–P00.03 (max. output frequency)
0.00–50.00s
0.0–100.0%
0.00–50.00s
0.0–3600.0s
0: switch over after zero frequency
1: switch over after starting frequency
2: switch over after passing stop speed
and delay
0.00–100.00Hz
0: Set value of speed (the only detection
mode valid in SVPWM mode)
1: Detection value of speed
0: Terminal running command is invalid
at power up
1: Terminal running command is valid at
power up
0: Run at the lower limit frequency
1: Stop
2: Sleep
0.0–3600.0s (valid when P01.19 is 2)
0: Restart is disabled
1: Restart is enabled
0.0–3600.0s (valid when P01.21 is 1)
-76-
Chapter 5
Default
value
0.0%
0.00s
0
0
0.00Hz
0.00s
0.0%
0.00s
0.0s
0
0.50 Hz
1
0
0
0.0s
0
1.0s
