Goodrive350 series high-performance multi-function inverter
Function
Name
code
Speed of spindle
P22.01
orientation
Deceleration time
P22.02 of spindle
orientation
Spindle zeroing
P22.03
position 0
Spindle zeroing
P22.04
position 1
Spindle zeroing
P22.05
position 2
Spindle zeroing
P22.06
position 3
Spindle
P22.07 scale-division
angle 1
Spindle
P22.08 scale-division
angle 2
Spindle
P22.09 scale-division
angle 3
Spindle
P22.10 scale-division
angle 4
Spindle
P22.11
scale-division
Detailed parameter description
1: Position lock mode
Bit9: Positioning completion signal selection
0: Electric level signal
1: Pulse signal
Bit10: Z pulse signal source
0: Motor
1: Spindle
Bit11–15: Reserved
During spindle orientation, the speed of the position
point of orientation will be searched, and then it will
switch over to position control orientation.
Setting range: 0.00–100.00Hz
Deceleration time of spindle orientation.
Spindle orientation deceleration time means the time
needed for the inverter to decelerate from the max.
output frequency (P00.03) to 0Hz.
Setting range: 0.0–100.0s
Users can select the zeroing positions of four
spindles by terminals (function code 46, 47).
Setting range: 0–39999
Setting range: 0–39999
Setting range: 0–39999
Setting range: 0–39999
Users can select seven spindle scale-division values
by terminals (function code 48, 49 and 50).
Setting range: 0.00–359.99
Setting range: 0.00–359.99
Setting range: 0.00–359.99
Setting range: 0.00–359.99
Setting range: 0.00–359.99
-205-
Chapter 6
Default Modi
value fy
10.00Hz
○
3.0s
○
0
○
0
○
0
○
0
○
15.00
○
30.00
○
45.00
○
60.00
○
90.00
○
