Appendix M
Panel Installation:
Follow all installation requirements for the lightleeDer panel listed in the manual. The lightleeDer panel is con g-
ured at the factory for emergency and normal loads, eld installation requires landing loads to the relays and making
the required connections to the power transformer and PMM.
1. Review submittal documents and con rm the relays to be used for emergency control
2. land the emergency circuits at the designated relays
3. Verify jumper setting on the RBOM for the eM relays are set to "On"
4. Verify voltage dividers if required
5. land the phase "A" un-switched normal power to the panels transformer
* see Figure 3 and PMM information for monitoring all 3 phases of normal power
Optional LightSync 0-10V Dimmer Module:
The Optional lightsync Dimmer Module (lsDM) or (ls-IDM) can be added to an emergency panel local data line bus
CAT-5 connection for remote mounting. This 0-10VDC dimmer control module will revert the dimming output con-
trol to a full brightness or 100%-on/non-dim level when local bus power is lost to the dimmer module.
During a normal power outage, the lightleeDer processor (ll-CPU), being powered by normal power feed, would be
off-line, causing any lightsync device on its local bus power to be off. Follow all standard dimmer control module in-
structions and wiring requirements in Appendix A.
Phase Monitoring Module Option Details:
The Phase Monitoring Module (PMM) can be added to the lightleeDer emergency panel for monitoring up to three
phases of the normal AC power system. This is used to ensure that when any of the three phases drops, the
lightleeDer emergency relay panel will react as an emergency event. The power from the transformer is run to the
PMM, and then to the power distribution card. The PMM will interrupt normal power, with an on board interrupt
relay when it senses a loss of any phase.
leD status indicators for all 3 phases, and a test button are provided.
An auxiliary status output relay is provided for signaling others systems. The PMM has connection terminals for the
normally open/normally closed auxiliary output, this isolated relay is rated 1 Amp@ 30VDC (see Figure 3).
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
