3.9.3 Viewing Current Firmware Revision

The internal rmware is what controls the hardware in the panel. This
may be updated with new features as time go on. Follow the steps
below to view the current rmware revision along with the node ad-
dress and the number of outputs connected.
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press until sPeCIAl FUnCTIOns appears
3. Press sPeCIAl FUnCTIOns
4. Press FIRMWARe ReVIsIOn

3.9.4 Diagnostics

each panel has some built-in diagnostics to help set the system up
including relay cycle test, device nder, input tester, and backup
and restore.
Cycle Test Relays:
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press until sPeCIAl FUnCTIOns appears
3. Press sPeCIAl FUnCTIOns
4. Press FIRMWARe ReVIsIOn
5. Press and hold and
6. Press 7 times
7. Press DIAgnOsTICs
8. Press CYCle TesT RelAYs
9. Press PeRFORM TesT, the relays will cycle OFF-On-OFF, then
go to their previous state
10. Press or to scroll through the test results
for each relay
11. Press hOMe to exit
Find LightSync, Dimmer, or Motor Devices
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press until sPeCIAl FUnCTIOns appears
3. Press sPeCIAl FUnCTIOns
4. Press FIRMWARe ReVIsIOn
5. Press and hold and
6. Press 7 times
7. Press DIAgnOsTICs
8. Press FInD DeVICes
9. Press lIghTsYnC DeVICes, DIMMeR DeVICes, or
MOTOR DeVICes to initiate a scan
10. Press or to scroll through the test results for each scan
11. Press hOMe to exit
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
eDIT (Networked Panels
buttons to enter a hidden menu
eDIT (Networked Panels
buttons to enter a hidden menu
Viewing Current Firmware Revision
EDIT NAMES
CHANGE PASSWORDS
FIRMWARE REVISION
From the sPeCIAl FUnCTIOns screen,
press FIRMWARe ReVIsIOn
ILC LIGHTLEEDER
REV 1.50 11/08/10
RELAYS:08
LL4 MODE NODE.01
Cycle Test Relays
EDIT NAMES
CHANGE PASSWORDS
FIRMWARE REVISION
From the sPeCIAl FUnCTIOns screen,
press FIRMWARe ReVIsIOn
ILC LIGHTLEEDER
REV 1.50 11/08/10
RELAYS:08
LL4 MODE NODE.01
Press and hold and
CLEAR TIMERS
CLEAR TIMER/RLY MAP
CLEAR PRESETS
DIAGNOSTICS
Press DIAgnOsTICs
CYCLE TEST RELAYS
FIND DEVICES
TEST INPUT DEVICES
BACKUP/RESTORE DATA
Press CYCle TesT RelAYs
Find LightSync, Dimmer, or Motor Devices
CYCLE TEST RELAYS
FIND DEVICES
TEST INPUT DEVICES
BACKUP/RESTORE DATA
From the sPeCIAl FUnCTIOns screen,
press FInD DeVICes
FIND DEVICES
LIGHTSYNC DEVICES
DIMMER DEVICES
MOTOR DEVICES
Press lIghTsYnC DeVICes, DIMMeR DeVICes,
or MOTOR DeVICes. scroll to see each device.
buttons
