Intelligent Lighting Controls, Inc. LightLEEDer Operation Manual page 45

Programming
Astronomical Time Scheduling
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press TIMeRs
3. Press COnFIgURe TIMeRs
4. Press or to select 1 of the 128 timers
5. Press AsTRO
6. Press sUnRIse or sUnseT
7. Press or to adjust any offset desired for the sUnRIse or
sUnseT timer
8. Press to clear any offset programmed
Open-Close-Time Control
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press TIMeRs
3. Press COnFIgURe TIMeRs
4. Press or to select 1 of the 128 timers
5. Press OPen/ClOse
6. Press OPen or ClOse
7. Press or to adjust any offset desired for the OPen or
ClOse timer
8. Press to clear any offset programmed
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
eDIT (Networked Panels
Astronomical Time Scheduling
TIMER TIMER.001
TIME 12:00AM
DAYS SMTWTFS
CONDITIONALS
From the COnFIgURe TIMeRs screen,
press TIMe
CLEAR TIMER
NORMAL
ASTRO
OPEN/CLOSE
Press AsTRO
TIMER.001
SUNRISE SR +000MIN
SUNSET
CLEAR OFFSET
Press sUnRIse or sUnseT then scroll
to the desired settings
Open-Close-Time Control
TIMER TIMER.001
TIME UNUSED
DAYS
CONDITIONALS
From the COnFIgURe TIMeRs screen,
press TIMe
CLEAR TIMER
NORMAL
ASTRO
OPEN/CLOSE
Press OPen/ClOse
TIMER.001
OPEN OPN+000MIN
CLOSE
CLEAR OFFSET
Press OPen or ClOse then scroll to
the desired settings
