Appendix l
Mapping Matrix Key
Column 1 "RC node" = Room Controller node address
Column 2 "RC func" = Relay number in Room Controller panel
Column 3 "Relay" = Relay number used in expansion Controller for programming the relays
Column 4 "ls node" = lightsync node numbers used at this address
Column 5 "local Port" = Address for programming the 2 local lightsync devices, and 2 onboard lightsync
photocell controllers
Column 6 "In 1" = lightsync input 1 , and photocell input 1 for the device in that row
Column 7 "In 2" = lightsync input 2, and photocell input 2 for the device in that row
Column 8 "In 3" = lightsync input 3, and photocell input 3 for the device in that row
Column 9 "In 4" = lightsync input 4, and photocell input 4 for the device in that row
Column 10 "In 5" = lightsync input 5, and photocell input 5 for the device in that row
Column 11 "In 6" = lightsync input 6, and photocell input 6 for the device in that row
Column 12 "In 7" = Onboard hardwired input (Occupancy sensor Input) 1, 3, and photocell input 7 for the device
in that row
Column 13 "In 8" = Onboard hardwired input (Occupancy sensor Input) 2, 4, and photocell input 8 for the device
in that row
Column 14 "Dim node" = The dimmer node numbers used at this address
Column 15 "Output" = The dimmer address for each output with nn = node number of the expansion Controller
connected to
Column 16 "RC" = The Room Controller dimming output number
Programming
Relays in these remote panels are programmed as if they were installed in the panel.
lightleeDer-2RC and -4RC panels have lightsync device addresses built into each unit for 2 - 6 button lightsync
push button switches (these addresses include the hardwire occupancy sensor inputs), 2 lightsync photocells,
and 1 lightsync dimmer. Refer to the mapping matrix to determine the device addresses used in each remote
panel address.
Notes:
• even if the lightsync devices in the Room Controllers are not used, the addresses cannot be used for other external
devices on the local network.
• lightsync devices must be con gured in the controller as if it is an external device.
• every remote panel uses 4 relay positions, including the ll-2RC.
• The lightleeDer-4X panels only use the rst 3 columns in the mapping matrix.
