Intelligent Lighting Controls, Inc. LightLEEDer Operation Manual page 85

Appendix J
RJ-45 Data
connectors
3.5"
Switch Inputs and
Pilot Outputs
3.25"
Remote Mounting Enclosure
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
Remote Mount
IN OUT
2 PILOT
1 PILOT
1 ON 2 ON
1 OFF 2 OFF
1 COM 2 COM
3 PILOT 4 PILOT
4 ON
3 ON
4 OFF
3 OFF
4 COM
3 COM
EXT +V
EXTCOM
77013485A
2.75"
LightSync Input Board
Photocell head RJ-45 Data
input connection connectors
2.5"
5.6"
2.5"
Controller
LightSync Photocell Controller
Node address settings
(Each device must be set to a
unique node address)
Panel Mount
IN
3.5"
1 PILOT
1 ON
1 OFF
Switch Inputs and
1 COM
Pilot Outputs
3 PILOT
3 ON
3 OFF
3 COM
77013485A
Node address settings
(Each device must be set to a unique
node address)
Outdoor
1.3"
Indoor 1.375"
OUT
2 PILOT
2 ON
2 OFF
2 COM
4 PILOT
4 ON
4 OFF
4 COM
EXT +V
EXTCOM
2.75"
Standard 1/2" conduit
thread.
1. 1 8"
Adhesive backing
.625"
1.0"
Sensors
.375"
