Programming

3.7.5 Program Open and Close Times

This will set the times when your facility opens and closes. Times set for
a speci c date (or holiday) supersedes the normal times of the week.
Times for Day-Of-Week
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press TIMeRs
3. Press OPen/ClOse TIMes
4. This screen displays today's Open and Close times
5. Press eDIT
6. Press DAY OF WeeK
7. Press or , to select the day
8. Press OPen, then Press
9. Press ClOse, then Press
10. Press " hOMe" to exit to the home screen
Times for a specific date
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press TIMeRs
3. Press OPen/ClOse TIMes
4. This screen displays today's Open and Close times
5. Press eDIT
6. Press CAlenDAR
7. Press or , to select the month
8. Press DATe, then Press
9. Press eDIT
10. Press or , to select the Open time
11. Press ClOse then Press
12. Press CleAR to clear times programming for that date
13. Press " hOMe" to exit to the home screen
Reset all Open and Close Times
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press TIMeRs
3. Press OPen/ClOseD TIMes
4. Press eDIT
5. Press ReseT All TIMes
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
or to adjust the OPen time
or to adjust the ClOse time
eDIT (Networked Panels
or , to select the date
or , to select the close time
eDIT (Networked Panels
Times for Day-Of-Week
CONFIGURE TIMERS
TIMER/RELAY CONTROL
OFF HOURS SWEEPS
OPEN/CLOSE TIMES
From the TIMeRs screen, press
OPen/ClOse TIMes
TODAY OPEN/CLOSE
OPEN 08:00 AM
CLOSE 09:00 PM
EDIT NOW:OPEN
Press eDIT
OPEN/CLOSE TIMES
DAY OF WEEK
CALENDAR
RESET ALL TIMES
Press DAY OF WeeK. select the day, Press
OPen or ClOse then scroll to the desired time.
Times for a specific date
CONFIGURE TIMERS
TIMER/RELAY CONTROL
OFF HOURS SWEEPS
OPEN/CLOSE TIMES
From the TIMeRs screen, press
OPen/ClOse TIMes
TODAY OPEN/CLOSE
OPEN 08:00 AM
CLOSE 09:00 PM
EDIT NOW:OPEN
Press eDIT
OPEN/CLOSE TIMES
DAY OF WEEK
CALENDAR
RESET ALL TIMES
Press CAlenDAR
OPEN/CLOSE TIME
MONTH JAN/01
DATE OP --:-- -M
EDIT CL --:-- -M
scroll to the month and date,
then press
DATE: JAN/01
OPEN OP --:-- -M
CLOSE CL --:-- -M
CLEAR
Press OPen or ClOse then
scroll to the desired time
eDIT
