Intelligent Lighting Controls, Inc. LightLEEDer Operation Manual page 67

Programming
3) Map the timers to control the relays.
1. From the home screen, node 01 press
2. Press TIMeRs
3. Press TIMeR/RelAY COnTROl
4. Press TIMeR/RelAY
5. Press until TIMeR 001 appears in the TIMeR eld.
6. Press RelAY, then press
in the RelAY eld.
7. Press ACTIOn until On appears in the ACTIOn eld.
8. Repeat steps 6 and 7 for relays 01.07 and 01.08.
9. Press TIMeR then
eld.
10. Press RelAY; then
eld.
11. Press ACTIOn then Press
12. Repeat steps 10 and 11 for relays 01.07 and 01.08.
13. Press the hOMe button to return to the node 01 home screen.
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT
or until the RlY: 01.06 appears
until Timer 002 appears in the TIMeR
until RlY:01.06 appears in the RelAY
to select OFF
ILC LIGHTLEEDER
TUE 01/21/11.
09:46:54
EDIT NODE
Press eDIT
RELAYS
INPUTS
TIMERS
CLOCK
Press TIMeRs
CONFIGURE TIMERS
TIMER/RELAY CONTROL
OFF HOURS SWEEPS
OPEN/CLOSE TIMES
Press TIMeR/RelAY COnTROl
TIMER/RELAY
TIMER/GROUP
TIMER/PRESET
Press TIMeR/RelAY, then
TIMER TIMER.001
RELAY RLY:01.03
ACTION NONE
Press RelAY, then
TIMER TIMER.001
RELAY RLY:01.06
ACTION OFF
Press ACTIOn
TIMER TIMER.001
RELAY RLY:01.06
ACTION ON
Repeat for relays 01.07 and 01.08.
Follow steps 9-12 to program relays
01.06, 7 and 8 to turn OFF with Timer 002
PM.
01.
or
