Intelligent Lighting Controls, Inc. LightLEEDer Operation Manual page 80

Appendix e
BACnet Module (panel level)
BACnet is an open protocol developed by AshRAe for building automation and control systems. lightleeDer BACnet
MsTP or IP modules give you direct control of the panel. With the panel module, commands can be sent to the panel
to force relays On and OFF, force relays On and OFF with a timer option (blink, double blink, hID delay, Alarm On,
Alarm OFF, Pulse On, and Pulse OFF), monitor relay status, monitor input status, and enable/disable inputs.
Setup:
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press 2 times to scroll down
3. Press OTheR DeVICes
4. Press ADD-On MODUles
5. Press ADD-On MODUle 1, 2, 3, or 4
6. Press or and select the PROTOCessOR option
RJ45 to BACnet
Ribbon connector to panel
termination
3.5"
2.0"
LightLEEDer BACnet IP
Control Module
(Panel level)
For a LightLEEDer BACnet point map go to:
http://ilc-usa.com/product_detail.php?pid=32
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
RS485 BACnet
Ribbon connector to panel
cable termination
J3
+
3.5"
D2
C6
+
R3
Y1
- C1
C7
R1
+
C2
-
U1 + +
C5
C3
+ -
77013517A
97013517
2.0"
LightLEEDer BACnet MSTP
Control Module
(Panel level)
BACnet Module Setup
ILC LIGHTLEEDER
EDIT
Press
TIMERS
CLOCK
PRESETS
OTHER DEVICES
Press
ADD-ON MODULES
DIMMER OUTPUTS
MOTOR OUTPUTS
Press
ADD-ON MODULE 1
ADD-ON MODULE 2
ADD-ON MODULE 3
C11
-
ADD-ON MODULE 4
PWR
Press ADD-On MODUle 1, 2, 3, or 4
RX
TX
ADD-ON MODULE 1
TYPE:PROTOCESSOR
EDIT
Press
the PROTOCessOR option
TUE 01/21/11.
09:46:54 PM.
NODE 01.
eDIT, then twice
OTheR DeVICes
ADD-On MODUles
or and select
