Programming
Relay Groups (Single Panel)
4. Press RelAY gROUPs
5. Press or to select the group and see the status of the
group
6. Press TURn On to force the group On
7. Press TURn OFF to force the group Off
Relay Groups (Networked Panels)
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. From the home screen, press
3. Press RelAYs
4. Press gROUP sTATUs
5. Press or to select the group and see the
status of the group
6. Press TURn On to force the group On
7. Press TURn OFF to force the group Off

3.6.8 Sweep all Relays in a Panel On and OFF

1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press RelAYs
3. Press RelAY sTATUs
4. Press sWeeP RelAYs
5. Press All On to force all relays On
6. Press All OFF to force all relays Off
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
eDIT
eDIT (Networked Panels
Relay Groups (Single Panel)
RELAY STATUS
SINGLE RELAY
RELAY GROUPS
SWEEP RELAYS
From the RelAYs/RelAY sTATUs
screen, press RelAY gROUPs
GROUP.001 IS OFF
TURN ON
TURN OFF
scroll to the desired group, then
Press TURn On or OFF to force the group
Relay Groups ( Networked Panels)
GROUP STATUS
INPUT MAPPING
From the RelAY screen, press
GROUP.001 IS OFF
TURN ON
TURN OFF
scroll to the desired group, then
Press TURn On or OFF to force the group
Sweep all Relays in a Panel On and OFF
RELAY STATUS
SINGLE RELAY
RELAY GROUPS
SWEEP RELAYS
From the RelAYs/RelAY sTATUs
screen, press sWeeP RelAYs
SWEEP RELAYS
ALL ON
ALL OFF
Press All On or All OFF to sweep relays
gROUP sTATUs
