Programming

3.10.3 Set time and date example

In the example the time/date is Wednesday January 5, 2011. The
Time is 11:15 AM. The network controller will sync all the other con-
troller nodes clocks to this time and date.
1. From the node 01 home screen press
until ReMOTe PAnel appears on the screen.
2. Press ReMOTe PAnel.
3. Press COnneCT to access the network Controller (node 00)
home screen.
4. Press eDIT. Then Press
choice.
5. Press ClOCK. Then Press
6. Press TIMe; then Press
hOUR eld. Be sure that it is 11 AM.
7. Press MInUTe; then Press
8. Press seT.
9. Press DATe; then Press
MOnTh eld.
10. Press DATe; then Press
11. Press YeAR; then Press
12. Press seT WeD 01/05/11 appears in the DATe eld.
13. Press the hOMe button to return to the node 01 home screen
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT. Then Press
until ClOCK appears as a menu
TIMe/DATe.
or until 11 appears in the
or until 15 appears.
or until 01 appears in the
or until 05 appears.
or until 2011 appears.
ILC LIGHTLEEDER
TUE 01/21/11.
09:46:54
EDIT NODE
Press eDIT, then
CLOCK
PRESETS
OTHER DEVICES
REMOTE PANEL
Press ReMOTe PAnel
REMOTE PANEL
NODE 00
CONNECT
Press COnneCT
ILC LIGHTLEEDER NC
TUE 01/21/11.
09:46:54
EDIT
Press eDIT, then
INPUTS
RELAYS
TIMERS
CLOCK
Press ClOCK, then TIMe/DATe
SET TIME/DATE
TIME 07:04:33 AM
DATE TUE 01/04/11
Press TIMe, MInUTe then
to set, then press
SET TIME/DATE
TIME 11:15:00
DATE WED 01/05/11
Press DATe then
MONTH 01/04/11
DATE
YEAR
SET
Follow steps 9-12, press hOMe
PM.
01.
3 times
PM.
.
or
seT.
AM
or
