Intelligent Lighting Controls, Inc. LightLEEDer Operation Manual page 84

Appenndix I
Sleek, contemporary styling
Choice of colors – standard Ivory, White,
Black, Gray, Brushed Aluminum or Stain-
less Steel – custom colors available
®
Lexan or stainless steel
screwless cover, painted
steel with screws available
Durable buttons
Engraved switch
identification available
(10 character max.)
Choice of colors – Ivory or White
Lexan ® cover
Location
Light LED
Durable buttons
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
Standard Front CAT-5 Back
ADDRESS
800-922-8004
IN
Status LEDs
Node
address
settings
(Each switch must be set
to a unique node address)
Classic LightSync Switch
Sleek, contemporary styling
Front
Node
address
settings
(Each
switch
must be
set to a
unique
node
address)
Status LEDs
G2 LightSync Switch
Direct Wired Back
OUT
1.75"
RJ-45 Data
connectors
2.75"
Back
1.437"
RJ-45 Data
connectors
4" 4.5"
4.125" 4.875"
