3.0 Information
In this section you will learn how to program a lightleeDer lighting control system through the keypad. software is
available on our website that simpli es the task and allows programming remotely.
Programming can be accomplished through any keypad in any panel in a networked system. To access a panel other
than the one you're at, press
node number and connect. The keypad is comprised of a 4 line 20 character lCD with 8 interface buttons. The 4 left
buttons corresponds to each line on the display and is pressed to enter that portion of the menu. The center 2
right buttons and are for scrolling up and down in the menu. The lower right "BACK" button will navigate you
back 1 screen each time it is pushed and the upper right "hOMe" button will navigate you back to the home screen.
Below are the suggested basic programming steps for the lightleeDer panels. Panel programming will vary
depending on the complexity of the system. see section 3.9 for programming samples.
1. setup network panels (section 3.1)
2. Clear system memory (section 3.3)
3. set the time, longitude/latitude, and time zone (section 3.4)
4. Con gure the relay types, output off types, and relay locks
(section 3.5)
5. Con gure relay groups (section 3.5.5) and presets (section 3.8)
6. Con gure lightsync devices and input types (section 3.6)
7. Map inputs to relays and groups (section 3.5.6)
8. Con gure timers (section 3.7)
9. Map timers to relay control (section 3.7.3)
Note: For Networked Panel Systems, certain settings are pro-
grammed at the system level in the Network Controller (Node
00). If you are at a panel other than the one that contains the
Network Controller use the steps below.
Connect to the Network Controller
1. From the home screen press
2. scroll until ReMOTe PAnel appears
3. Press ReMOTe PAnel
4. Press or until nODe 00 is displayed
5. Press COnneCT
6. Follow single panel menu from this point
Connect to Networked Panels
1. From the home screen press
2. scroll until ReMOTe PAnel appears
3. Press ReMOTe PAnel
4. Press or until desired nODe is displayed
5. Press COnneCT
6. Follow single panel menu from this point
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT, scroll down until ReMOTe PAnel appears, Press
eDIT
eDIT
ReMOTe PAnel, select the
Connect to a Networked Panel
ILC LIGHTLEEDER
TUE 01/21/11.
09:46:54
EDIT NODE
Press eDIT
CLOCK
PRESETS
OTHER DEVICES
REMOTE PANEL
Press ReMOTe PAnel
REMOTE PANEL
NODE 02
CONNECT
Press COnneCT
PM.
01.
