Timer Control:
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press 2 times to scroll down
3. Press OTheR DeVICes
4. Press MOTOR OUTPUTs (motor output screen)
5. Press OUTPUT then
6. Press COnFIgURe (control screen)
7. Press TYPe until "TIMeR" appears
8. Press sOURCe
9. Press or to select the timer to activate the action.
10. Press BACK
11. Press ACTIOn then Press
action appears (see table 3.8)
12. Press RUn TIMe then
required
13. Press hOMe to exit
Preset Control:
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press 2 times to scroll down
3. Press OTheR DeVICes
4. Press MOTOR OUTPUTs (motor output screen)
5. Press OUTPUT then
6. Press COnFIgURe (control screen)
7. Press TYPe until "PReseT" appears
8. Press sOURCe
9. Press or to select the preset to activate the action.
10. Press BACK
11. Press ACTIOn then Press
tion appears (see table 3.13)
12. Press RUn TIMe then
required
13. Press hOMe to exit
Table 3.13: Available Programming Actions
Stop: Upon input contact the the motor output will open or stop.
Run Positive: When contact is made on the input the motor output
will go positive with an adjustable output of .1 second to 10 seconds
in .1 second increments, 10 to 300 second increments, or latched.
Run Negative: When contact is made on the input the motor output
will go negative with an adjustable output of .1 second to 10 seconds
in .1 second increments, 10 to 300 second increments, or latched.
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
or to select the device channel (1-4)
ACTIOn until the desired
or to adjust the "On" time
eDIT (Networked Panels
or to select the device channel (1-4)
ACTIOn until the desired ac-
or to adjust the "On" time
Motor Controller Timer Control
DEVICE 01
ACTIVE: YES
OUTPUT: M:01.01.1
CONFIGURE (COM)
From the MOTOR OUTPUTs screen, press
COnFIgURe, then TYPe
CONTROL 01
TYPE:TIMER
SOURCE
ACTION
Press sOURCe then BACK
CONTROL 01
TIMER: TIMER.001
Press ACTIOn then RUn TIMe
CONTROL 01
ACTION: RUN-POS
RUN TIME=000.1
Motor Controller Preset Control
DEVICE 01
ACTIVE: YES
OUTPUT: M:01.01.1
CONFIGURE (COM)
From the MOTOR OUTPUTs screen, press
COnFIgURe, then TYPe
CONTROL 01
TYPE:PRESET
SOURCE
ACTION OUT1:OFF
Press sOURCe then BACK
CONTROL 01
PRESET: PRESET.001
Press ACTIOn then RUn TIMe
CONTROL 01
ACTION: RUN-POS
RUN TIME=000.1
