3.5.5 Setup a Toggle Source

This must be set when using a Momentary Push-Button Toggle
switch type.
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press InPUTs
3. Press or to select the device node number
4. Press COnFIgURe InPUTs
5. Press TYPes
6. Press TOggle sOURCe
7. Press or to select the device node number
8. Press RelAY
9. Press or to select the relay number
10. Press hOMe to exit to the home screen

3.5.6 Configure Input Conditionals

An AnD conditional can be set to allow switch activation only when
both conditions are true. An OR conditional can be set to allow
switch activation when either conditional is true.
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press InPUTs
3. Press or to to select the device node number
4. Press COnFIgURe InPUTs
5. Press COnDITIOnAls
6. Press COnDITIOn A (set condition B for your second
conditional if desired)
7. Press or to select the condition type. Refer to table 3.3
Table 3.3: Conditional Types
Relay ON: Any chosen relay that is presently On
Relay OFF: Any chosen relay that is presently OFF
ON input closed: Any chosen On input that is closed
ON input open: Any chosen On input that is open
OFF input closed: Any chosen OFF input that is closed
OFF input open: Any chosen OFF input that is open
Note: switch inputs must be programmed with a switch type to function
