Programming

3.9 Controller System Functions

This section will show how to access some of the controller system
functions like naming, passwords, rmware revisions, diagnostics, and
backup.

3.9.1 Naming Panels, Relays, Groups, Timers, and Presets

names can be programmed into the system to identify panel loca-
tion, relay control areas, group functions, and preset functions. This
section also describes how to switch between custom and default
programming.
Panel Name:
Note: It is suggested that the node number be included in the naming of
the panel.
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press until sPeCIAl FUnCTIOns appears
3. Press sPeCIAl FUnCTIOns
4. Press eDIT nAMes
5. Press eDIT PAnel nAMe
6. Press or to scroll to the space to edit
7. Press or to change to the desired letter,
number, or character.
8. Press or to scroll to the next space to edit
9. Continue until all characters have been edited
10. Press sAVe to store the programming
11. Press hOMe
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
Naming Panels
ILC LIGHTLEEDER
TUE 01/21/11.
09:46:54 PM.
EDIT NODE 01.
Press eDIT
PRESETS
OTHER DEVICES
REMOTE PANEL
SPECIAL FUNCTIONS
Press sPeCIAl FUnCTIOns
EDIT NAMES
CHANGE PASSWORDS
FIRMWARE REVISION
Press eDIT nAMes
EDIT PANEL NAME
EDIT RELAY NAMES
EDIT GROUP NAMES
EDIT TIMER NAMES
Press eDIT PAnel nAMe
DEFAULT PANEL NAME
ILC LIGHTLEEDER
^
SAVE
Press or then scroll
to the desired character
