Appendix h
N2 Module (panel level)
The lightleeDer Controller(s) can be integrated into a Building Automation system (BAs) that uses the n2 communi-
cations protocol. The host system can then poll the status of the lightMaster Controller inputs and outputs and issue
On/OFF commands to the lightleeDer 's relay outputs. With the panel module, commands can be sent to the panel
to force relays On and OFF, force relays On and OFF with a timer option (blink, double blink, hID delay, Alarm On,
Alarm OFF, Pulse On, and Pulse OFF), monitor relay status, monitor input status, and enable/disable inputs.
Setup:
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press
2 times to scroll down
3. Press
OTheR DeVICes
4. Press
ADD-On MODUles
5. Press
ADD-On MODUle 1, 2, 3, or 4
6. Press
or
and select the n2 option
Device addressing
switches
ADDRESS
3.0"
77013492A
97013492
LightLEEDer N2 Control Module
(Panel level)
For a LightLEEDer N2 point map go to:
http://ilc-usa.com/product_detail.php?pid=32
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
N2 cable
termination
Ribbon connector to panel
2.0"
N2 Module Setup
ILC LIGHTLEEDER
TUE
01/21/11.
09:46:54
EDIT
NODE
Press
eDIT, then
TIMERS
CLOCK
PRESETS
OTHER DEVICES
Press
OTheR DeVICes
ADD-ON MODULES
DIMMER OUTPUTS
MOTOR OUTPUTS
Press
ADD-On MODUles
ADD-ON MODULE 1
ADD-ON MODULE 2
ADD-ON MODULE 3
ADD-ON MODULE 4
Press
ADD-On MODUle 1, 2, 3, or 4
ADD-ON MODULE 1
TYPE:N2
EDIT
Press
or
and select
the n2 option
PM.
01.
twice
