Programming
1,2,3,4,5, or 6 Pushbutton: lightsync data line push-
button switch stations in Classic, g2 or touch switch
Momentary ON/OFF: When momentary contact is
made between the On and COM, relay outputs con-
trolled by this input shall be turned On. When mo-
mentary contact is made between OFF and COM, relay
outputs controlled by this input shall be turned OFF.
Momentary ON/OFF w/Blink: When momentary
contact is made between the On and COM, relay out-
puts controlled by this input shall be turned On. When
momentary contact is made between OFF and COM,
relay outputs controlled by this input shall blink and
postpone being turned OFF. The alert time shall be
programmable from 2 to 99 minutes. The blink alert
function shall blink each relay twice prior to turning
OFF. If an On command is received during the blink
alert time, relay output shall be overridden and left On
for the override time. Override times shall be ad-
justable from 5 to 999 minutes in 1-minute increments.
Note: Output must be programmed for a blink alert.
see section 3.6.2
Momentary Push-Button ON/OFF: When mo-
mentary contact is made between the On and
COM, relay outputs controlled by this input are
turned On and OFF alternately, based on current
state of the switch.
Momentary Push-Button ON: When momentary
contact is made between the On and COM, relay
outputs controlled by this input shall be turned On.
Momentary Push-Button OFF: When momentary
contact is made between On and COM, relay outputs
controlled by this input shall be turned OFF.
Momentary Push-Button Toggle: When momen-
tary contact is made between On and COM, relay
outputs controlled by this input shall toggle from
the present state. note: Toggle source must be set
as shown in section 3.6.5.
Maintained ON/OFF: When contact is made be-
tween the On and COM, relay outputs controlled
by this input are turned On. When contact is bro-
ken between On and COM, relay outputs con-
trolled by this input are turned OFF. Note: Requires
toggle function programming. see section 3.5.5
Maintained Multi-way: When contact is either made
or broken between the On and COM, relay outputs
controlled by this input will be toggled between On
and OFF conditions. This function shall be similar to
that of standard 3 and 4 way switches.
Maintained ON/OFF w/Blink: When contact is made
between the On and COM, relay outputs controlled
by this input are turned On. When contact is broken
between On and COM, relay outputs controlled by
this input shall blink and postpone being turned OFF.
The alert time shall be programmable from 2 to 99
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
Table 3.2: Input Types:
minutes. The blink alert function shall blink each relay
twice prior to turning OFF. If an On command is re-
ceived during the blink alert time, relay output shall
be overridden and left On for the override time.
Override times shall be adjustable from 5 to 999 min-
utes in 1-minute increments. Note: Output must be
programmed for a blink alert. see section 3.6.2
Timed ON: The timed On input shall operate either
from the input closure or open. If programmed to
operate from the closure, the relays turn On when
the input closes and turn OFF after the timed dura-
tion. The relays do nothing when the input opens. If
programmed to operate from the open, the relays
turn On when the input closes and remain On.
When the input opens, the relays turn OFF after the
timed On duration.
HID Bi-Level: This feature requires the con gura-
tion of On/OFF relay outputs and hI/lOW relay out-
puts. The rst momentary contact between On and
COM sets the On relay outputs to On and the
hI/lOW outputs to hIgh (for at least 15 Minutes).
The second contact switches the hI/lOW outputs
to lOW. Additional contact closures will toggle the
hI/lOW relay outputs. The cycle then repeats until
momentary contact is made between switch input
OFF and COM. Then the On/OFF outputs and
hI/lOW outputs are turned OFF.
Two-Step Alternating Sequence: The rst time
the switch is activated, relay outputs programmed
as "group A" are turned On and relay outputs pro-
grammed as "group B" are turned OFF. The second
time the switch is activated, "group A" relay outputs
are turned OFF and "group B" relay outputs are
turned On. The third time the switch is activated,
the pattern begins again at step one.
Four-Step Alternating Sequence: The rst time the
switch is activated, relay outputs programmed as
"group A" are turned On and relay outputs pro-
grammed as "group B" are turned OFF. The second time
the switch is activated, "group A" relay outputs are
turned OFF and "group B" relay outputs are turned On.
The third time the switch is activated; both "group A"
and "group B" relay outputs are turned On. The fourth
time the switch is activated; both "group A" and "group
B" relays are turned OFF. The fth time the switch is ac-
tivated, the process begins again at step one.
Set Preset: When momentary contact is made be-
tween the On and COM, the selected preset scene
will be activated.
Force Timer: When momentary contact is made
between the On and COM, the selected timer will
be activated.
Disabled: When this is selected the inputs will not be
active. If the Disabled switch input type A or B is set to
an Input Active Time the switch input will be ignored.
