Programming
4) Program Relays 25, 27 in Node 04 into Group 003.
1. From the node 01 home screen press
until ReMOTe PAnel appears on the screen.
2. Press ReMOTe PAnel
3. Press until nODe 04 appears then Press
access controller node 04's home screen.
4. Press eDIT. Then Press
RelAYs.
5. Press until gROUP .003 appears in the gROUP eld.
6. Press RelAY. Then Press
RelAY eld.
7. Press InClUDe until Yes appears in the InClUDe eld
8. Repeat steps 6 and 7 substituting 04.27 into the RelAY eld.
9. Press the home Button to return to node 01 home screen.
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT. Then press
COnneCT to
RelAYs; then Press gROUP
until RlY: 04.25 appear in the
ILC LIGHTLEEDER
TUE 01/21/11.
09:46:54
EDIT NODE
Press eDIT, then 3 times
CLOCK
PRESETS
OTHER DEVICES
REMOTE PANEL
Press ReMOTe PAnel then
REMOTE PANEL
NODE 04
CONNECT
Press COnneCT
ILC LIGHTLEEDER 04
TUE 01/21/11.
09:46:54
EDIT
Press eDIT
NETWORK
INPUTS
RELAYS
TIMERS
Press RelAYs
RELAY STATUS
RELAY OPTIONS
GROUP RELAYS
INPUT MAPPING
Press gROUP RelAYs, then
RELAY GROUPS
GROUP: GROUP.003
RELAY: RLY:04.25
INCLUDE: YES
Press RelAY, then
RELAY GROUPS
GROUP: GROUP.003
RELAY: RLY:04.25
INCLUDE: NO
Press InClUDe
RELAY GROUPS
GROUP: GROUP.003
RELAY: RLY:04.25
INCLUDE: YES
Repeat for Relay 27, Press hOMe
