Programming

3.8 Configure Relay Presets

Relays can be programmed into preset On or OFF patterns that can
be activated by a timer, switch, or other external command.

3.8.1 Setup Presets

1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press to scroll down to PReseTs
3. Press PReseTs
4. Press eDIT PReseTs
5. Press or to select the preset to program
6. Press RelAY
7. Press or to select the relay
8. Press ACTIOn until the desired action is displayed
9. Press " hOMe" to exit to the home screen

3.8.2 Capture Presets

Using this programming method will capture the relays present
On/OFF state in every panel. Use the above method if you want relays
to be excluded from the On/OFF pattern.
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press to scroll down to PReseTs
3. Press PReseTs
4. Press CAPTURe PReseTs
5. Press or to select the preset to program through
a Capture
6. Press CAPTURe
7. Press " hOMe" to exit to the home screen

3.8.3 Activate a Preset and View Status

For non-networked panels:
1. From the home screen, press
connect to the Network Controller Node 00 as shown in
Section 3.0)
2. Press to scroll down to PReseTs
3. Press PReseTs
4. Press ACTIVATe PReseTs
5. Press or to select the preset to activate (note: status is
shown in this screen)
6. Press ACTIVATe
7. Press " hOMe" to exit to the home screen
ILC LightLEEDer Operation Manual
Version 1C 3/14/17
eDIT (Networked Panels
eDIT (Networked Panels
eDIT (Networked Panels
Setup Presets
INPUTS
TIMERS
CLOCK
PRESETS
Press PReseTs
EDIT PRESETS
ACTIVATE PRESETS
CAPTURE PRESETS
Press eDIT PReseTs
PRESET PRESET.001
RELAY RLY:01.01
ACTION:NONE
Press PReseT and scroll to the desired
preset. Then press RelAY and scroll to the
desired relay. Then Press
scroll to the desired action.
Capture Presets
EDIT PRESETS
ACTIVATE PRESETS
CAPTURE PRESETS
From the PReseT screen, press
CAPTURe PReseTs
CAPTURE A PRESET
PRESET:PRESET.001
CAPTURE
scroll to the desired preset,
then press CAPTURe
Activate a Preset and View Status
EDIT PRESETS
ACTIVATE PRESETS
CAPTURE PRESETS
From the PReseT screen, press
ACTIVATe PReseTs
ACTIVATE A PRESET
PRESET:PRESET.001
STATUS:TRUE
ACTIVATE
scroll to the desired preset,
then press ACTIVATe
ACTIOn and
