Analog Electronic Modules
• Smoothing with 4AI I 2WIRE Standard
1
0.63
0.5
0
• Smoothing with 2AI U High Speed, 2AI I 2WIRE High Speed, 2AI I 4WIRE High
Speed
None: k=1
1
0.63
0.5
0
Figure 12-6
12-40
weak: k=4
None: k=1
25
weak: k=64
100
Smoothing with 2AI U High Speed, 2AI I 2WIRE High Speed, 2AI I 4WIRE
High Speed
medium: k=16
50 75
Module cycles
medium: k=128
200 300
Module cycles
strong: k=32
100 125
strong: k=512
400 500
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
150
600
