VLT® Soft Starter MCD 600
Operating Guide
Normal 350%, 30 s, 4 starts per hour
A hp @240 V AC
MCD6-0979C 864 350
MCD6-1134C 966 400

3.6 Dimensions and Weight

A
B
READY RUN TRIP LOCAL
Exit Menu
Reset Store
C D
1/L1 3/L2 5/L3
2/T1 4/T2 6/T3
Illustration 4: Dimensions and Weight
Table 12: Dimensions and Weight
Width [mm (in)]
A
MCD6-0020B
MCD6-0034B
MCD6-0042B
MCD6-0063B
152 (6.0)
MCD6-0069B
MCD6-0086B
MCD6-0108B
MCD6-0129B
MCD6-0144B
MCD6-0171B
MCD6-0194B
216 (8.5)
MCD6-0244B
MCD6-0287B
Danfoss A/S © 2020.12
hp @480 V AC hp @600 V AC
700 900
800 1000
E
C D
Height [mm (in)]
B C
92 (3.6) 336 (13.2)
495 (19.5)
180 (7.1)
523 (20.6)
Heavy 450%, 30 s, 4 starts per hour
A hp @240 V AC
722 300
784 300
A
B
READY RUN TRIP LOCAL
Back Menu
Reset Store
Depth [mm (in)]
D E
307 (12.1) 231 (9.1)
450 (17.7) 243 (9.6)
AQ262141844215en-000401 / 175R1174 | 19
System Design
hp @480 V AC hp @600 V AC
600 700
600 800
E
Weight [kg (lb)]
4.8 (10.7)
4.9 (10.9)
5.5 (12.1)
12.7 (28)
15.5 (34.2)
