Precautions For Handling - IAI ROBO Cylinder RCS4-WRA12C Instruction Manual

1. The Safety Guide attached with the product is intended to permit safe use of
the product and thus to prevent risks and property damage. Be sure to read it
before handling the product.
2. Do not attempt any handling or operation that is not indicated in this instruction
manual.
3. Make sure to secure the actuator properly in accordance with this instruction
manual.
If the actuator is not securely fixed, this may lead to abnormal noise, vibration, breakdown or
shortened product life.
4. Make sure to observe the usage conditions and environment of the product.
Operation outside the warranty could cause decreased performance or product breakdown.
Use within the allowable range for each item.
Item
Speed and
acceleration/deceleration
Rod Tip Dynamic
Allowable Load
Load offset distance

Precautions for Handling

Cautions
for use
Use within the
allowable
range
Use within the
allowable
range
Problems or breakdowns which may
occur if the allowable
range is exceeded
May lead to abnormal noise, vibration,
breakdown, or shortened product life.
May lead to abnormal noise, vibration,
breakdown, or shortened product life.
In extreme cases, flaking may occur on the
guide or ball screw.
Mounting a load with an overhang length
greater than the allowable values may lead
to vibration or abnormal noise.
Precautions for Handling
Intro-9
