Flange Bracket (Model Code: FL)

It is a bracket to affix the actuator from the main body side with screws.
[Model code of single product: RCP6-FL-WRA10]
H7 +0.012
φ6
Through
0
[Model code of single product: RCP6-FL-WRA12]
H7 +0.015
φ8
Through
0
7
(59)
118
130
RCS4-WRA10C and WRA10R
9
(72)
144
160
RCS4-WRA12C and WRA12R
4-φ6.6 Through
Oblong Hole
Through
13
(43)
4-φ9 Through
Oblong
Hole
Through
17
(47)
1.3 Options
