1.2 Specifications
[Sideways lnstallation]
Item
[kg]
Allowable Payload
(Operating life
3,000km
[kg]
Remaining
Probability
90%)
[kg]
Center of
Gravity Load
Rod Tip Offset
Distance
1-89
Stroke 50 100
Rod Tip Offset
Distance 20.3 17.4 15.1 13.4 11.9 10.7
0mm
Rod Tip Offset
Distance 17.4 15.8 14.1 12.6 11.3 10.2
75mm
Rod Tip Offset
Distance 10.2 10.2 10.2 10.2 10.2
150mm
150 200 250 300 350
9.6
9.2
9.7 8.8
Stroke
400 450 500 550 600
8.7 7.9 7.2 6.5 5.9
8.4 7.6 6.9 6.3 5.8
8.1 7.4 6.7 6.1 5.6
