6) Tighten up the pulley cover with the pulley cover affixing screws in the specified
torque.
Pulley Cover
Pulley Cover Affixing Screw
Pulley Cover Affixing Screw Tightening Torque
Model
WRA10R
WRA12R
WRA14R
Type of Screws
Cross-recessed Button Head
Screw (SUS): M3
4.6 How to Replace Components
Tightening
Torque [N•m]
0.9
4-16
