1.2 Specifications
[Sideways lnstallation]
Item
[kg]
Allowable Payload
(Operating life
5,000km
[kg]
Remaining
Probability
90%)
[kg]
Center of
Gravity Load
Rod Tip Offset
Distance
1-27
Stroke 50 100
Rod Tip Offset
Distance 15.0 13.5
0mm
Rod Tip Offset
Distance 14.2 12.6
50mm
Rod Tip Offset
Distance 10.2 10.2
100mm
150 200 250 300 350
11.7 10.3 9.1 8.2 7.3
11.1 9.8 8.8 7.9 7.1
10.2 9.4 8.5 7.6 6.9
Stroke
400 450 500
6.6 6.0 5.5
6.5 5.9 5.3
6.3 5.7 5.2
