IAI ROBO Cylinder RCS4-WRA12C Instruction Manual page 33

[Sideways lnstallation]
Item
[kg]
Allowable Payload
(Operating life
5,000km
[kg]
Remaining
Probability
90%)
[kg]
Center of
Gravity Load
Rod Tip Offset
Distance
Stroke 50 100
Rod Tip Offset
Distance 10.0 10.0
0mm
Rod Tip Offset
Distance 10.0 9.8
50mm
Rod Tip Offset
Distance 5.1 5.1
100mm
150 200 250 300 350
9.3 8.1 7.2 6.5 5.8
8.6 7.7 6.9 6.2 5.6
5.1 5.1 5.1 5.1 5.1
Stroke
1.2 Specifications
400 450 500
5.3 4.8 4.4
5.1 4.6 4.2
4.9 4.5 4.1
1-14
