6.5.4.2

Mounting of the SICAM I/O Modules

The SICAM I/O Modules can be mounted as shown in following picture.
LK1
ETH
X1
PK1
LK4
ETH
X4
PK4
OH2
RS-2 3 2
X2
RTX2
RY ER
X7
LK7 PK7
X3
RTX3
OH3
RY
X6
RTX6 OH6
Note
The tongue and groove system integrated in the modules facilitates the correct combination. The module
is only connected correctly when the locking hook is snapped onto the DIN rail.
Caution
To increase the stability it is necessary to mount an end clamp flush left from the CP-802x housing and
flush right after the last SICAM I/O Module.
RY
LK7
X3
RTX3
X6
RTX6
You can take information on the SICAM I/O Modules out of the following document:
Document name
SICAM I/O Modules User Manual
Please consider the notes in the section 2.1.5.4,
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
RY ER
-
X1
+
LK1
ETH
X1
PK1
LK4
ETH
X4
PK4
OH2
RS-2 3 2
X2
RTX2
RY RY
RY
ER RY ER
X7
PK7
-
OH3
X1
OH6 +
RY
Configuration Rules for I/O
Unrestricted
Installation and Circuitry
Item number
DC8-012-2
Modules.
193
