Evaporator Saturated Refrigerant Temperature

Keypad Menu Path:
Menu
\Unit
\Refrigerant (1)
Measurement
Temperature
BACnet
Compressor Select
This output network variable indicates the current saturated refrigerant temperature in the evaporator. There is a separate output
for each compressor. See Compressor Select on page
Object Type
Analog Input
Compressor #2
This output network variable indicates the current saturated refrigerant temperature in the evaporator for compressor 2. (A89) Not
available on all chiller models.
Object Type
Analog Input
LONWORKS
Variable Details
This output network variable indicates the current saturated refrigerant temperature in the evaporator. There is a separate output
for each compressor. See Compressor Select on page
LONWORKS Name
nvoSatEvapRefTemp
www.DaikinApplied.com
Units
BACnet: °F
LONWORKS: Fixed Point
LONWORKS: °C
Scalar signed long
43. (A16)
Object Identifier
Type Enumeration
0
Object Identifier
Type Enumeration
0
Comp2EvapSatRTmp
43. (A16)
Profile
Proprietary
Data Type Valid Range
BACnet: Real
BACnet: -40°–244°F
LONWORKS: -40°–118°C
Instance Property Name
14 Present Value
Object Name
EvapSatTemp
Instance Property Name
70 Present Value
Object Name
SNVT Type SNVT Index
temp_p
67 ED 15062-7 • MICROTECH II CHILLER CONTROLLER
d d P I
eTaIled aTa oInT
Default Value
NA
Property Identifier
Property Enumeration
85
Property Identifier
Property Enumeration
85
SNVT Size
105 two bytes
nformaTIon
