Compressor Select

Keypad Menu Path:
This input network variable selects the compressor/circuit (number 1, 2, 3, 4, 5 or 6) that is interrogated.
The controller returns the information for the selected compressor/circuit. You must first select a
No Keypad Equivalent
compressor/circuit then interrogate the selected compressor/circuit. This variable selects a compressor/
circuit for the following variables. See
determine which of these variables will be available. (I32)
Name
Compressor Current
Compressor Discharge Temperature
Compressor Percent RLA
Compressor Power
Compressor Run Hours
Compressor Starts
Compressor Status
Compressor Voltage
Condenser Refrigerant Pressure
Condenser Saturated Refrigerant Temperature
Measurement
Event Count
BACnet
Variable Details
Object Type
Multi-state Output
LONWORKS
Variable Details
LONWORKS Name
nviCompSelect
Valid Range
1 = Comp/Circuit No. 1
2 = Comp/Circuit No. 2
3 = Comp/Circuit No. 3 (Circuit No. 1 on Scroll Chillers and Condensing Units)
4 = Comp/Circuit No. 4 (Circuit No. 2 on Scroll Chillers and Condensing Units)
5 = Comp No. 5 (Circuit No. 1 on Scroll Chillers and Condensing Units)
6 = Comp No. 6 (Circuit No. 2 on Scroll Chillers and Condensing Units)
