Evaporator Refrigerant Pressure

Keypad Menu Path:
Menu
\View
\Comp (2)
Measurement
Pressure (gauge)
BACnet
Compressor Select
This output network variable indicates the current refrigerant pressure in the evaporator. There is a separate output for each
compressor. See Compressor Select on page
Object Type
Analog Input
Compressor #2
This variable indicates the current refrigerant pressure in the evaporator for compressor 2. Not available on all chiller models. (A90)
Object Type
Analog Input
LONWORKS
Variable Details
This output network variable indicates the current refrigerant pressure in the evaporator. There is a separate output for each
compressor. See Compressor Select on page
LONWORKS Name
nvoEvapRefPress
ED 15062-7 • MICROTECH II CHILLER CONTROLLER
Units
BACnet: psi
LONWORKS: Fixed-Point
LONWORKS: kPa
Scalar signed long
43. (A17)
Object Identifier
Type Enumeration
0
Object Identifier
Type Enumeration
0
Comp2EvapPress
43. (A17)
Profile
Proprietary
Data Type Valid Range
BACnet: Real BACnet: -22592–22591 psi
LONWORKS:
-3,276.8 ... 3,276.7 kPa
Instance Property Name
13 Present Value
Object Name
EvapPressure
Instance Property Name
71 Present Value
Object Name
SNVT Type SNVT Index
press
66
d d P I
eTaIled aTa oInT
Default Value
NA
Property Identifier
Property Enumeration
85
Property Identifier
Property Enumeration
85
SNVT Size
30 two bytes
