Network Control Property
Keypad attributes available as BACnet
Standard Objects for network control
of the unit
Compressor Select
Compressor Starts
Compressor Select
Compressor #2
Compressor #3
Compressor #4
Compressor Status
Compressor Select
Compressor #2
Compressor #3
Compressor #4
Compressor #5
Compressor #6
Compressor Suction Line Temperature
Compressor Select
Compressor #2
Compressor Voltage
Compressor Select
Compressor #2
Compressor #3
Compressor #4
Compressor #5
Compressor #6
*Condenser Entering Water
Temperature (7)
Condenser Flow Switch Status
*Condenser Leaving Water
Temperature (8)
Condenser Pump Run Hours
Pump Select
Pump #2
Condenser Refrigerant Pressure
Compressor Select
Compressor #2
Condenser Saturated Refrigerant
Temperature
Compressor Select
Compressor #2
Condenser Water Flow Rate
Condenser Water Pump Status
*Cool Setpoint (9)
Design RPM
Compressor #1
Compressor #2
*Evaporator Entering Water
Temperature (5)
Evaporator Flow Switch Status
*Evaporator Leaving Water
Temperature for Unit (6)
Evaporator Leaving Water
Temperature for Compressor
Compressor Select
Compressor #2
*Boldface denotes data points for typical minimum integration.
ED 15062-7 • MICROTECH II CHILLER CONTROLLER
Description
43 W MSO 46 1=Comp1, 2=Comp2, 3=Comp3, 4=Comp4, 5=Comp5, 6=Comp6
AI 25
44 R AI 92 0–65,535
AI 100
AI 108
Bitwise logic:
AI 123
0=OFF
AI 91
1=Start Oil Pump,
45 R AI 99 2=Interlock/Prelube,
3=Run
AI 107
4=Shutdown
AI 115
5=Postlube
AI 121
47 R AI 15 -40°–244°F
AI 69
AI 52
AI 79
48 R AI 98 0–65,535
AI 106
AI 114
AI 120
50 R AI 3 -40°–244°F
51 R BI 35 0=No Flow, 1=Flow
52 R AI 4 -40°–244°F
Hours reported at 1/10th the actual hours.
53 R AI 28 0–65,535
AI 90 0–65,535
54 R AI 16 -3276.8–3276.7
AI 74 -3276.8–3276.7
AI 17 -40°–244°F
55 R
AI 73 -40°–244°F
56 R AI 50 Flow Rate in GPM Centrifugals Only
57 R BI 37 0=No Flow, 1=Flow
58 W AO 29 10 – 120°F; Default=44°F
60 R AI 63 0–32678
AI 64
61 R AI 1 -40°–244°F
62 R BI 34 0=No Flow, 1=Flow
63 R AI 2 -40°–244°F
64 R AI 23 -40°–244°F
AI 68 -40°–244°
C
