This section lists the information (i.e. data) that is available to
the BAS via BACnet or LONWORKS communication protocols.
This information is used to safely operate and log the
performance of the chiller. The systems integrator also uses
this information when creating custom graphics.
Table 2: Data Points for Chiller Models
Data Point
Active Setpoint
Actual Capacity
Actual RPM
Capacity Limit (LONWORKS Configuration)
Capacity Limit Output
Capacity Limit Setpoint
Cavity Temperature
Chiller Enable
Chiller Enable (LONWORKS Configuration)
Chiller Limited
Chiller Local/Remote
Chiller Location
Chiller Mode (LONWORKS Configuration)
Chiller Mode Output
Chiller Mode Setpoint
Chiller ON OFF
Chiller Status BACnet
Chiller Status (LONWORKS)
Chiller Type
Compressor Current**
Compressor Discharge Temperature
Compressor Percent RLA
Compressor Power**
Compressor Run Hours
Compressor Select
Compressor Starts
Compressor Status
Compressor Suction Line Temperature
Compressor Voltage**
Condenser Entering Water Temperature
Condenser Flow Switch Status
Condenser Leaving Water Temperature
Condenser Pump Run Hours
Condenser Refrigerant Pressure
Condenser Saturated Refrigerant
Temperature
Condenser Water Flow Rate
Condenser Water Pump Status
Cool Setpoint
Cool Setpoint (LONWORKS Configuration)
Current Alarm
*Dual Circuit Only
**Optional Solid State Starter Required. Voltage, Power and Current are per compressor
***Not available on the WMC
****AGS A and B vintage only
*****WMC only
