Active Setpoint

Keypad Menu Path: This output network variable indicates the current value of the setpoint temperature used to control the
temperature of the Leaving Chilled Water or Leaving Hot Water. Based on the operating mode of the
Menu
chiller, this value is derived from the Cool Setpoint, Heat Setpoint, or Ice Setpoint. The default mode is
\Set
Cooling and is used unless changed by the Mode input. (A2)
\Unit SPs (3)
Measurement
Temperature
BACnet
Variable Details
Object Type
Analog Input
LONWORKS
Variable Details
LONWORKS Name
nvoActiveSetpt

Actual Capacity

Keypad Menu Path: This output network variable indicates the percent of capacity the chiller is currently producing. It may
be more or less than the nominal capacity of the chiller. For Centrifugal chiller models, this data point
No Keypad Equivalent
represents the combined percent RLA of the compressors. For positive displacement chillers (those
using screw and scroll compressors) this is a percentage of total compressors running. (A10)
Measurement
Percent of chiller capacity
BACnet
Variable Details
Object Type
Analog Input
LONWORKS
Variable Details
LONWORKS Name
nvoActCapacity
www.DaikinApplied.com
Units
BACnet: °F
LONWORKS; Fixed Point
LONWORKS: °C
Scalar signed long
Object Identifier
Type Enumeration
0
ActiveLvgWaterTarget
Profile
Chiller
Units
NA
LONWORKS: Fixed-Point
Scalar signed long
Object Identifier
Type Enumeration
0
Profile
Chiller
Data Type Valid Range
BACnet: Real
BACnet: -40°–199° F
LONWORKS: -40°–93°C
Instance Property Name
7 Present Value
Object Name
SNVT Type
temp_p
Data Type Valid Range
BACnet: Real
Instance Property Name
9 Present Value
Object Name
ChillerCapacity
SNVT Type
lev_percent
23 ED 15062-7 • MICROTECH II CHILLER CONTROLLER
d d P
eTaIled aTa oInT
Default Value
Property Identifier
Property Enumeration
SNVT Index SNVT Size
105
Default Value
0–160%
Property Identifier
Property Enumeration
SNVT Index SNVT Size
81
I
nformaTIon
NA
85
two bytes
NA
85
two bytes
