Compressor Voltage

Keypad Menu Path:
No Keypad Equivalent
Measurement
Electric Voltage
BACnet
Compressor Select
This output network variable indicates the current compressor voltage. There is a separate output for each compressor. See
Compressor Select on page
Object Type
Analog Input
Compressor #2
This variable indicates the current compressor voltage for compressor 2. It is available via BACnet only.(A98)
Object Type
Analog Input
Compressor #3
This variable indicates the current compressor voltage for compressor 3. It is available via BACnet only.(A112)
Object Type
Analog Input
Compressor #4
This variable indicates the current compressor voltage for compressor 4. It is available via BACnet only.(A117)
Object Type
Analog Input
Compressor #5
This variable indicates the current compressor voltage for compressor 5. It is available via BACnet only.(A122)
Object Type
Analog Input
ED 15062-7 • MICROTECH II CHILLER CONTROLLER
Units
BACnet: VAC
LONWORKS: Fixed Point
LONWORKS: VAC
43. (A29)
Object Identifier
Type Enumeration
0
Object Identifier
Type Enumeration
0
Object Identifier
Type Enumeration
0
Object Identifier
Type Enumeration
0
Object Identifier
Type Enumeration
0
Data Type
BACnet: Real
LONWORKS: 0–65,534
Scalar unsigned long
Instance
52
Object Name
Voltage
Instance
79
Object Name
Comp2Voltage
Instance
98
Object Name
Comp3Voltage
Instance
106
Object Name
Comp4Voltage
Instance
114
Object Name
Comp5Voltage
48
d d P
eTaIled aTa oInT
Valid Range Default Value
BACnet:
Property Identifier
Property Name Property Enumeration
Present Value
Property Identifier
Property Name Property Enumeration
Present Value
Property Identifier
Property Name Property Enumeration
Present Value
Property Identifier
Property Name Property Enumeration
Present Value
Property Identifier
Property Name Property Enumeration
Present Value
www.DaikinApplied.com
I
nformaTIon
NA
85
85
85
85
85
