Condenser Refrigerant Pressure

Keypad Menu Path:
Menu
\View
\Unit
\Refrigerant (1)
Measurement
Pressure (gauge)
BACnet
Compressor Select
This output network variable indicates the current refrigerant pressure in the selected condenser. There is a separate output for
each compressor. See Compressor Select on page
Object Type
Analog Input
Compressor #2
This variable indicates the current refrigerant pressure for compressor 2. Not available on all chiller models. (A93)
Object Type
Analog Input
LONWORKS
Variable Details
LONWORKS Name
nvoCondRefPress
ED 15062-7 • MICROTECH II CHILLER CONTROLLER
Units
BACnet: psi
LONWORKS: Fixed-Point
LONWORKS: kPa
Scalar signed long
43. (A21)
Object Identifier
Type Enumeration
0
Object Identifier
Type Enumeration
0
Comp2CondPress
Profile
Proprietary
Data Type Valid Range
BACnet: Real BACnet: -22592–22591 psi
LONWORKS:
-3,276.8...3,276.7 kPa
Instance Property Name
16 Present Value
Object Name
CondPressure
Instance Property Name
74 Present Value
Object Name
SNVT Type SNVT Index
press
54
d d P I
eTaIled aTa oInT
Default Value
NA
Property Identifier
Property Enumeration
85
Property Identifier
Property Enumeration
85
SNVT Size
30 two bytes
