Chiller Mode Setpoint

Keypad Menu Path:
The Chiller Mode data point determines the mode of operation of the chiller. LONWORKS network
variables set the default and operating chiller mode. The BACnet property is a commandable property of
Menu
a Multi-state Output object. Refer to the appropriate Operating Manual for suitable variable values. (I17)
\Set
\Unit SP (1)
Measurement
HVAC Mode
BACnet
This commandable property sets the mode of operation of the chiller and provides the ability for another node on the network to
place a chiller in another mode.
Variable Details
Object Type
Multi-state Output
Default Value (Relinquish_Default): 2
LONWORKS
Input (nvi)
This input network variable sets the mode of operation of the chiller and provides the ability for another node on the network to
place a chiller in another mode.
Variable Details
LONWORKS Name Profile
nviMode Chiller
hvac_mode
All enumerations are not used for this data point. Only the following enumerations are used.
Value
1 HVAC_HEAT
3 HVAC_COOL
11
www.DaikinApplied.com
Units
NA
Object Identifier
Type Enumeration
14
SNVT Type
hvac_mode
Identifier Notes
Heating only
Cooling only
HVAC_ICE Ice-making mode
Data Type
BACnet: Unsigned Integer
LONWORKS: Fixed Point
Scalar - unsigned long
Instance
45
Object Name
ChillerOperationMode
Property Values
1. ICE
2. COOL
3. HEAT
SNVT Index SNVT Size
108 one byte
31 ED 15062-7 • MICROTECH II CHILLER CONTROLLER
d d P
eTaIled aTa oInT
Valid Range Default Value
See Below
Property Identifier
Property Name Property Enumeration
Present Value
SCPT Reference
NA
I
nformaTIon
See Below
85
SCPT Index
NA
