Protocol Implementation Conformance Statement (PICS)
This section contains the Protocol Implementation
Conformance Statement (PICS) for the MicroTech II Chiller
Unit Controller of Daikin Applied as required by ANSI/ASHRAE
Standard 135-2004, BACnet: A Data Communication Protocol
for Building Automation and Control Networks.
BACnet Protocol Implementation
Conformance Statement
Date:
Vendor Name:
Product Name:
Product Model Number:
Applications Software Version:
Firmware Revision:
BACnet Protocol Revision:

Product Description

The MicroTech II Chiller Unit Controller with optional BACnet
Communication Module is a microprocessor-based controller
designed to operate Daikin Applied chillers and be integrated
into BACnet building automation systems.

BACnet Standardized Device Profile

 BACnet Operator Workstation (B-OWS)
 BACnet Building Controller (B-BC)
 BACnet Advanced Application Specific Controller (B-AAC)
 BACnet Application Specific Controller (B-ASC)
 BACnet Smart Sensor (B-SS)
 BACnet Smart Actuator (B-SA)
ED 15062-7 • MICROTECH II CHILLER CONTROLLER
June 2015
Daikin Applied
MicroTech II Chiller Unit Controller
MTII Chiller UC
2.00
AmBCM-10 - BmBCM-485-15E
Version 1
Revision 4
BACnet Interoperability Building Blocks
(BIBBs) Supported
BIBB Name
Data Sharing – ReadProperty – B
Data Sharing – ReadPropertyMultiple – B
Data Sharing – WriteProperty – B
Data Sharing – WritePropertyMultiple – B
Alarm and Event – Notification Internal – B
Alarm and Event – ACK – B
Alarm and Event – Information – B
Device Management – Dynamic Device Binding – B
Device Management – Dynamic Object Binding – B
Device Management – DeviceCommunicationControl – B
Device Management – TimeSynchronization – B
Device Management – UTCTimeSynchronization – B
Device Management – ReinitializeDevice – B
Device Management – Restart – B

Standard Object Types Supported

□ □
Analog Input
□ □
Analog Output
□ □
Binary Input
□ □
Binary Value
□ □
Device
□ □
Multi-state
Input
□ □
Multi-state
Output
1. Read_Ony is a read only proprietary property used to indicate whether the
Present_Value is read-only (0), writeable but not commandable (1) or writeable
and commandable (2).
102
a
PPendIx
Designation
DS-RP-B
DS-RPM-B
DS-WP-B
DS-WPM-B
AE-ACK-B
AE-INFO-B
DM-DDB-B
DM-DOB-B
DM-DCC-B
DM-TS-B
DM-UTC-B
DM-RD-B
Description
Read_Only
Reliability
Description Relinquish
Read_Only
Reliability Default
Description
Reliability
Read_Only
Inactive_Text
Active_Text
Description
Reliability
Present
Inactive_Text
Value
Active_Text Read_Only
Relinquish
Priority Array
Default
Relinquish Default
Profile_Name
Description
Location
Local_Time
Local_Date
Location
UTC_Offset
Daylight_Savings_
Status
Max_Master
Max_Info_Frames
Description
Reliability Read_Only
State_Text
Description
Relinquish
Reliability Read_Only
Default
State_Text
